• Tank Size: 150 Gallon

  • Engine: 4.8 HP (3.6 kw) Honda

  • Weight: 1,725 lbs

Dimensions (trailer configuration)

  • Length: 12' 1”
  • Width:  6’ 4”
  • Height:  5’ 9”
  • Tank:  300 gallons

Trailer Specifications (for trailer configuration)

  • 6,000 lb axle with a pintle eye
  • 5,000 lb jackleg
  • Wired for towing
  • Tires:  ST 225/75D15
  • Electric brakes on axle
  • Safety chains
  • Emergency breakaway switch with battery backup
  • Shipping weight: 1,725 lbs
  • Loaded weight:  3,400 lbs

Dimensions (skid-mount configuration)

  • Length: 7’ 6”
  • Width:  4’ 3” – skid frame width
  • Height:  4’ 9”
  • Tank:  150 gallons

Tank Dimensions

  • Length: 52”
  • Width:  54.125”
  • Height:  36.25”


  • 4.8 HP (3.6 kw) Honda
  • 1 gallon fuel tank

Heat System

  • One 300,000 BTU propane burner
  • One starter burner
  • 40 lbs propane fuel tank

Asphalt Pump

  • Specially designed 7 GPM pump

Temperature Gauge

  • 50 - 300⁰ F
  • Adjustable angle face plate

Flue Design

  • Five pass flue system
  • V-shaped profile
  • Aluminized exhaust stack


  • 20" diameter
  • 10" diameter fill hose
  • 3 osi pressure relief


  • 6’ wand with cold handles
  • On/off valve
  • Removable spray tip

Additional Standard Equipment

  • Waste bucket mount (trailer configuration only)
  • 1” Rear tank return
  • 2” tank overflow
  • Flush tank: 7 gallons tank with suck back valve
  • Hose and reel: .5” x 40’ heavy-duty recoil hose reel
  • Clean out: 4”
  • Sampling valve: 1”

Optional Equipment

  • Engines
    - Honda gas - 4.8 hp (3.6 kW) electric start
    - Hatz diesel - 7.2 hp (5.4 kW)  pull start or electric start
    - Fuel: 1.32 gallons
  • Heat Systems
    - Diesel Burner, One 300,000 BTU diesel burner  (only available with electric start engines)
    7 gallon fuel tank
    Auto ignition diesel burner with outfire

    - Overnight Heat
    120 volt/1500 watt
    Immersion element

  • 12’ Spray pattern
  • - Spray bar controls: In-truck wireless remote controls (requires spray bar option)
    - Spray bar lift with wireless remote control

  • Insulated Tank
  • 2-5/16” ball hitch

Training, Support and Company

  • Training and support manuals
  • Optional on-site operator training by Dealer
  • Two-year, unlimited hours warranty against any manufacturer defects
  • Extended warranty available
  • 55+ years manufacturing experience
  • ISO 9001 Certified
  • Sourcewell Contract#052417-VTL
  • Manufactured in the USA

Job Application

  • Driveways
  • Small to large parking lots
  • Cart paths
  • Municipal work
  • Patching

Key Features

  • 150 gallon capacity
  • Trailer or skid-mount configuration
  • One 300,000 BTU propane burner
  • 7 gpm asphalt pump
  • 7 gallon flush tank
